Features:
1.Auto cutting and Sticking circle or half circle of bottle. Auto melting and attaching glue on top and rear of the label , glue auto recycling .
2.Variable speed control system, synchronous automatic detection system, automatic adjust production speed, Always make the labeling machine at best production speed
3.Star Wheel separation and feeding ,correlation design transmission mode high-speed labeling, stable precision.
4.Abnormal situation, this machine has safety device ,automatic stop immediately.
5.Following conditions the machine will automatically stop and alarm:
(1) Label is not labeled on bottles
(2)Label sticker failure
(3)Label is about to run out
(4)Abnormal bottle feeding
(5)Abnormal bottle out
(6)Abnormal bottle jam
6.Techmach electronic automatic rectify guide system, digital electronic eye for ultrasound method.Non-contact electric eye, automatically adjust the label location. (optional).
7. Label top and end difference within 2mm ( without Techmach), 1mm （with techmach）
| MODEL | NCR-300 | NCR-400 | NCR-450 |
| Capacity | 18000 BPH | 24000 BPH | 30000 BPH |
| Power | 16KW | 18 KW | 20 KW |
| Machine Size | 2200L*2300W*2000H(mm) | 2200L*2500W*2000H(mm) | 2500L*2800W*2000H(mm) |
| Container Material | PET , PP , PE ,HDPE , Glass , Metal | ||
| Container Diameter | φ30-200 mm | ||
| Container Height | 100-500 mm (can be custimized) | ||
| Label Roll Inner Diameter | 6 inches(152mm) | ||
| Label Height | 20-250mm | ||
| Voltage | AC 3φ 380V/50HZ
|
||
| Air Consumption | 3-6 kg/cm² | ||
