Back seal-packing method, valve piston pump filling meter
Film disinfection, liquid disinfection
The finished packed products are elegant and reliable, hygiene and security.
Assembled with a photoelectric controller to ensure that its packing bag figure are perfect.
It can automatically finish making-bag, metering, filling, sealing, cutting, counting and printing batch number.
The body and the parts touching the material are made of stainless steel.
Suitable material
|
Technical specifications |
| 型号 |
Type |
NC-ZF1000
|
NC-ZF2000 |
NC-ZF4000 |
| 制成袋长 mm |
bag making length |
50-150 |
50-250 |
100-400 |
| 制成袋宽 mm |
bag making width |
65-150 |
65-175 |
65-210 |
| 包装薄膜宽度 mm |
packing film width |
150-320 |
150-380 |
150-450 |
| 包装容量 ml |
packing capacity |
50-550 |
200-1050 |
500-2000 |
| 包装速度 bags/h |
packing speed |
1100-1300 |
1100-1300 |
800-1000 |
| 功率 Kw |
power |
2.1 |
2.5 |
2.5 |
| 外形尺寸 mm |
Overall Dimension |
1050×850×2050 |
1050×850×2050 |
1200×850×2050 |
| 整机质量 Kg |
Weight |
370 |
380 |
460 |
|
